Chute Feeder
Introduction of Chute Feeder:
The chute feeder can be installed on the ground or onto discharge port of ore bin. The chute bottom plates do the reciprocating movement, the movement frequency is 20-60 times/min and the stroke is 20-200mm. Stroke can be adjusted by the eccentric wheel; the eccentric throw is half of the stroke. According to experience of some mine sites, the eccentric throw should no less than 30mm for cohesive ore. The chute width is 2-2.5 times of maximum feeding granularity. The biggest chute feeder can supply ore with granularity less than 500mm. the most common specification is 980*1240 chute feeder, with feeding granularity between 350-0mm, which is the best partner of 400*600 jaw crusher.
Features of Chute Feeder:
1).Steady vibration, safe operation, durable life.
2).Flux can be changed and controlled.
3).The machine can be adjusted steadily, low noise, low electricity consumption.
4).Simple structure, safe operation, light weight, small volume, easy to maintain.
Application of Chute Feeder:
The chute feeder is suitable for concentrating coal, chemical and other industry departments, the granular and pieces materials are carried into different set from the storage bin, but not suitable for carrying the concentrate power and other power materials.
Working Principle of Chute Feeder:
1).The chute feeder can be installed on the ground or onto discharge port of ore bin.
2).The chute bottom plates do the reciprocating movement. Stroke can be adjusted by the eccentric wheel; the eccentric throw is half of the stroke. According to experience of some mine sites, the eccentric throw should no less than 30mm for cohesive ore.
3).The chute width is 2-2.5 times of maximum feeding granularity. The biggest chute feeder can supply ore with granularity less than 500mm.
Main Technical Parameters:
|
Specification and type
|
Output size
|
Swinging times (c/min)
|
Swinging range
（mm）
|
Max feeding size
（mm）
|
Capacity
（t/h）
|
Rotating motor
|
||
|
Width
|
Height
|
Type
|
Power
(kw)
|
|||||
|
400x400
|
400
|
400
|
28
|
20-50
|
100
|
2.5-3
|
Y112M-6
|
2.2
|
|
600x500
|
600
|
500
|
30
|
20-50
|
200
|
5-10
|
Y132M-6
|
4
|
|
980x1200
|
900
|
700
|
25
|
20-50
|
250
|
20-40
|
Y160M-6
|
7.5
|
|
800x700
|
750
|
600
|
25
|
20-50
|
250
|
30-50
|
Y132M2-6
|
5.5
|
Note: The technical parameters above are just for your reference. If there is any change, all parameters and overall dimension are subject to operating instructions. Any questions please feel free to contact us.
