SZF Series Linear Vibrating Screen
Introduction of SZF series linear vibrating screen:
SZF series linear vibration screen is used as a source of vibration excitation by vibrating motor, so that the sieve material being thrown up and forward for linear motion, the material from the feeder evenly into the screening machine feed port, through the multi-screen produce several kinds of specifications on the screen material, screen material, under, respectively, discharged from their exports. With low energy consumption, high output, simple structure, easy maintenance, full-enclosed structure, no dust, auto-nesting, more suitable for pipelining.
Features of SZF series linear vibrating screen:
1). High screening efficiency, can be screened up to 200 meshes (0.074mm).
2). Less blocking of mesh screen.
3). Excellent seal function.
4). Simple structure.
5). Low energy consumption.
6). little noise.
7). Long working life.
Application of SZF series linear vibrating screen:
Vibrating screen is able to screen and grade for power and granule material. It is widely applied in plastic, abrasives, chemicals, medicine, building materials, food, carbon, fertilizer industries and so on.
Main Technical Parameters:
Model
|
A
|
B
|
C
|
D
|
E
|
F
|
G
|
H
|
I
|
K
|
SZF-520
|
2130
|
966
|
935
|
566
|
1700
|
600
|
235
|
200
|
150
|
400
|
SZF-525
|
2630
|
966
|
935
|
566
|
2200
|
600
|
235
|
200
|
150
|
400
|
SZF-1020
|
2130
|
1368
|
935
|
1068
|
1700
|
600
|
235
|
200
|
150
|
900
|
SZF-1025
|
2630
|
1368
|
935
|
1068
|
2200
|
600
|
235
|
200
|
150
|
900
|
Note: The technical parameters above are just for your reference. If there is any change, all parameters and overall dimension are subject to operating instructions. Any questions please feel free to contact us.
